Dakota Signature Series 12″ Tall Dual Function Pullout handle with a Simple Style Faucet

Description:

This sensor faucet with a single lever handle and an infrared wide range sensor is built of a sturdy low lead brass material and features a pull-down function. Using this motion sensor, you'll have the ease of being able to perceive and respond to what and when you need it, by activating or deactivating flow with the simple movement of your hand. After three minutes of inactivity, a safety timer will automatically shut the water supply. In addition, when the Spray Head is pulled from its housing, it will automatically turn on. For those who like the handle on a frequent basis, a manual override is available. It also contains flexible stainless steel braided connectors for simple installation.  The spout can be rotated 180 degrees, allowing for easier access to more parts of the sink.  ADA compliant – complies with the standards set forth by the Americans with Disabilities Act for kitchen faucets

Features:

• Overall Height: 12″ (measured from countertop to highest point of faucet)
• Spout Height: 9-7/8″ (measured from countertop to spout outlet)
• Spout Reach: 9″ (measured from the center of faucet base to center of spout outlet)
• Faucet Holes: 1 (number of holes required for faucet installation)
• Flow Rate: 1.5 GPM (gallons-per-minute)
• Designed for use with standard US plumbing connections
• All necessary mounting hardware included
• Two Function Spray Head
• Pull Out Kitchen Faucet
• Brass Water Way

• Zinc Handle

• Ceramic Disc Cartridge

• Neoperl Aerator

• Stainless Steel Braided Hose, US 3/8”, 50Cm Length

• Base Plate Not Included
• Faucet body constructed of brass
• Single handle operation
• Pullout spray faucet head with 20″ hose enhances faucets versatility
• Spout swivels 180-degrees providing greater access to more areas of the sink
• ADA compliant – complies with the standards set forth by the Americans with Disabilities Act for kitchen faucets
• Low lead compliant – meeting federal and state regulations for lead content

Specification

Product Dimensions
Product Height (in)	12
Products width(in)	8.97
Faucet Height (in)	9.88
Faucet Type	Pull-Out

Product Specification
Application	Kitchen
Number of Handle	1
Number of Installation Holes	1
Spray Head	2 Function
Flow Rate	1.5 GPM @ 60psi
Style	Pull-Out
Faucet	Kitchen Faucet
Certifications	cUPC® NSF/ANSI 61 AB1953 ADA Compliant
Warranty	Lifetime Limited Warranty

Included Accessories:
DSF-12KPO00CR	UPC:
DSF-12KPO00BN	UPC: 810006535884
DSF-12KPO00ORB	UPC:
DSF-12KPO00BKBN	UPC:
DSF-12KPO00BKNP	UPC:

User Manual & Installation Guides
